Hardver jellemzők
Csatlakozások 10/100Mbps Ethernet Port*2
USB 2.0 Port*1
Micro USB Port*1
Hálózati tápegység 802.3af/at PoE or Micro USB(DC 5V/Minimum 1A)
Dimensions 3.9×3.9×1.0in. (100×98×25mm)
JELLEMZŐK
Vezeték nélküli funkciók L3 Management
Multi-SSID
Load Balance
Band Steering
Airtime Fariness
Beamforming
Rate Limit
Wireless Schedule
QoS
Vezeték nélküli biztonság Captive Portal Authentication
Access Control
Wireless Mac Address Filtering
Wireless Isolation Between Clients
SSID to VLAN Mapping
Rogue AP Detection
AP vezérlés Automatic Discovery
Unified Configuration
Reboot Schedule
Batch Firmware Upgrade
LED ON/OFF
Hitelesítés Captive Portal
Vezérlés
Omada App Yes
Centralized Management
• Up to 500 Omada access points, JetStream switches, and SafeStream routers*
• Up to 15,000 clients
*Only some JetStream switches and Safestream gateways can be centrally managed by OC300, please refer to www.tp-link.com/business-networking/all-omada/ to find all the models supported by OC300
Cloud Access Yes
L3 Management Yes
Multi-site vezérlés Yes
Management Features
• Automatic Device Discovery
• Batch Configuration
• Batch Firmware Upgrading
• Intelligent Network Monitoring
• Abnormal Event Warnings
• Unified Configuration
• Reboot Schedule
• Captive Portal Configuration
Egyéb jellemzők
Tanúsítványok CE, FCC, RoHS
Csomagolás tartalma Omada Cloud Controller
OC200
Quick Installation Guide
Ethernet Cable
Rendszerkövetelmény Microsoft® Windows®10, 8, 7,Vista™, XP or MAC® OS, NetWare®, UNIX® or Linux
Környezet
• Operating Temperature: 0–50 ? (32–122 ?)
• Storage Temperature: -40–70 ? (-40–158 ?)
• Operating Humidity: 10–90% RH non-condensing
• Storage Humidity: 5–90% RH non-condensing
